NETZSCH Pumps & Systems India is the leading manufacturer of advanced pumping solutions customized for the unique requirements of lithium battery manufacturing. At the forefront, the NEMO Progressing Cavity pumps, TORNADO Rotary Lobe Pumps, and PERIPRO® Peristaltic pumps can transfer complex electrode slurry fluids and provide accurately metered flows of viscous, shear sensitive, and high solids-laden materials which makes them well suited for lithium battery production.

NEMO® Progressing cavity pumps belong to the group of rotary positive displacement pumps. The main components are a rotating rotor and a stationary stator. The rotor is hinged or elastically attached on one side. The hollow stator is elastic and has the same pitch length as the rotor.

This leaves conveying spaces between the stator and the rotor, which move continuously from the inlet to the outlet side. The size of the cavities and the associated delivery rate depend on the size of the construction. Except for the rotor and stator, all other components are identical.

NETZSCH NEMO® progressing cavity pumps can convey the battery industry’s wide range of abrasive slurries and harsh fluids without pulsation and meter them with extremely high precision. This is applied in the process of feeding, during mixing, grinding, dispersing, and coating or the precise dosing of anode and cathode slurries.

The mixing pumps accurately meter the raw materials for a perfect mix to ensure consistent and optimum battery performance. NEMO® pumps also precisely meter or transfer ceramic slurries, electrolytes, adhesives, resins, and many other battery process fluids including those with aggressive solvents.

Peristatic pumps belong to the group of rotating positive displacement pumps. They only have one wearing part, the hose. The product to be conveyed is forced through the hose by external mechanical deformation of the hose. The hose is supported by the housing of the pump head and is clamped by rollers. The rollers rotate on a rotor. The rotation causes the pinch-off point to move along the hose, thus propelling the pumped product. The elasticity of the hose material generates the suction vacuum. Due to their design, peristaltic pumps are insensitive to dry running.

PERIPRO® Peristaltic Pumps have a heavy-duty construction for demanding applications, with heavy-duty, precision machined elastomer hoses for +/-1% flow accuracy and large, easy-to-maintain rollers for longer service life.

Among the particular features of PERIPRO® Peristaltic Pumps that make them ideal for lithium battery manufacturing is the fact that it is a seal-less design, so no hazardous vapors or emissions can escape. Additionally, slurries up to 70% solids are easily conveyed with no exotic, hard alloys required for abrasion resistance.

When selecting chemical dosing pumps for specific applications, it is crucial to consider several factors to ensure the efficient and safe delivery of chemicals. In the dynamic landscape of industrial processes, precise and efficient chemical dosing is a critical element for ensuring optimal performance and safety.

Here is a guide to help you make a clever selection:

Chemical Compatibility:

Understand the chemical properties of the substances you intend to dispense. Choose a pump material that is compatible with the chemical being used to prevent corrosion or damage.

Flow Rate and Pressure Requirements:

Determine the required flow rate and pressure for your application. Select a pump that can handle the specific flow rate and pressure demands of your system to ensure accurate dosing.

Accuracy and Precision:

For applications that require precise dosing, choose a pump that offers high accuracy and repeatability to avoid over or under-dosing.

Control Options:

Consider the control options available for the pump, such as manual, automatic, or programmable control, depending on the complexity of your dosing requirements.

Environmental Conditions:

Assess the environmental conditions, including temperature, humidity, and potential exposure to external elements. Select a pump that can operate effectively within the specified conditions.

Maintenance and Service Requirements:

Evaluate the ease of maintenance and service requirements for the pump. Choose a pump that is easy to maintain and service to minimize downtime and operational costs.

Safety Measures: Prioritize pumps equipped with safety features such as leak detection, overload protection, and pressure relief valves to ensure the safety of personnel and the surrounding environment.

Cost Considerations: Balance the initial investment with the long-term operating costs. Consider the total cost of ownership, including energy consumption, maintenance, and replacement parts, to make an informed decision.

Reputation and Support: Research the reputation of the manufacturer and supplier. Opt for reputable brands that offer reliable customer support and after-sales services to address any issues or concerns that may arise.

Compliance with Industry Standards: Ensure that the selected pumps comply with relevant industry standards and regulations to maintain the integrity of your processes and meet legal requirements.

By considering these factors, you can make an informed decision and select the most suitable chemical dosing pump for your specific applications, ensuring optimal performance and safety.

Different types of chemical solvents are used in the Paint, Pigments, and Ink industry. NETZSCH pumps are designed for accurate metering and dosing and also ensure gentle and consistent flow.

Problem Identification

Paint manufacturing companies are struggling with a common problem, which is the repeated breakdown of their pumps used in the process of refilling offset ink from the transport truck to the storage tank. In most cases, the pumps engaged here are diaphragm pumps.

Because of such inadequacies, the unloading process was greatly delayed and the pumps needed a high amount of maintenance work, often requiring them to be removed completely and dismantled, which was a labor-intensive and time-consuming task.

The application requirements in the industry were for the spin flash dryer (to reduce moisture content in pigment-dewatered sludge cake). Feeding the dewatered sludge into the spin flash dryer, by a system that can give the required flow rate can transfer the thick viscous medium at an elevation of 8 – 10 meters and must be compact in size.

During initial testing which was done for a few minutes, the pump’s motor was tripping due to the dry running of the pump.

Due to the sticky nature of the material, the pump was getting choked thereby restricting the movement of the fluid, resulting in choking of the pump.

NETZSCH SOLUTION

Why Progressive cavity pump?

To increase the performance, economy, and reliability of the sludge handling system, the company decided to contact the pumping experts at NETZSCH Pumps & Systems to get a suitable solution.

On reviewing the problem, the NETZSCH NEMO® Progressing Cavity Pumps, a single-stage pump model with a BP module allowing for a higher delivery rate at a lower differential pressure was proposed and offered as our solution.

This system prevented excessive clamping thereby improving mechanical efficiency. Allowed space for multiple pump installations, due to compact nature. Enabled easy access to the devices in case maintenance work had to be carried out. Operated more reliably and efficiently than the previously employed diaphragm pumps, which resulted in the reduction of the unloading time for the ink by less than half of the time consumed earlier.

Other applications within the Paints, pigments, and ink industry facing similar challenges with fluid handling are:

• Filter press feeding (pigments & dyes)
• Spray dryer feeding (Highly acidic dyes & solvent-based dyes)
• Tank-to-tank transfer – NEMO / Tornado

Want to learn more about how the NETZSCH pump ranges, We can help you with your Industry application?

Get in touch with our team of experts. We can advise on best practices and recommend which pump will solve your tough challenge.

To send us an inquiry: https://shorturl.at/tvJKX

E-mail: info.nti@netzsch.com

Landline: 044 4296 5100

NETZSCH offers Progressive cavity pumps for the most demanding applications – slurries, high-viscosity products, suspended solids, concentrated acids, chemicals, high-temperature liquids, sludge, resins, sewage and scum, paints, polymers, plastics, pharmaceuticals, foods, shear sensitive fluids.

One of India's largest interior infrastructure companies, when it comes to plywood and MDF boards

• Plywood Manufacturing Process
• Debarking and chipping
• Chip washing
• Defibration
• Resin or Glue preparation
• Blow line
• Drying
• Mat Formation.

Application: Transferring of Hot wax / Emulsifiers:

NEMO SY Pump with capacity 600l/hr. @ pressure 18 bar, with sliding velocity 0.8m/s and rotation speed @ 441 rpm, and with motor capacity 1.5kW.

NEMO Pumps installed in a Glue preparation

Resin, Fungicide, Hardener, Additive, Urea

NETZSCH SOLUTION

NETZSCH Pumps in Plywood Manufacturing

NEMO is used in two different application sections in the plywood manufacturing process as follows:

Defibration Process:

Before the Defibration process, the chips are coated with molten paraffin wax or emulsifiers. The coating of wax or emulsifier is done by using NEMO.

Blow line:

From the deliberator, the pulp enters a blow line, where it is mixed with prepared glue. In this process, NEMO is used in feeding the prepared glue into the blow line.

NEMO Pumps in Glue feeding into Blow line

Why Progressive cavity pump?

Other pumping technologies used in the process of making plywood are as follows.

1. Diaphragm pump
2. Gear pump

While using a diaphragm pump in the coating of wax or emulsifier they had an issue of pulsation. Causes of Pulsation are as follows:

 * Nonuniform coating of wax or emulsifier in the pulp thus reduces the moisture handling capacity of the plywood.

 *Vibration in the pipeline and thus creates leaks in the connection ports.

Gear pumps also can be used to transfer the coloring agent, additives, resin, fungicides, etc., into the glue preparation tank. Here there are chances to shear the product and thus can lead to the chemical and physical property change of the fluid.

Also, there could be a seal leak issue in the resin and additive line.

The blow line has a line pressure of 12 bar, the pump has to work against this pressure and inline dosing of prepared glue to be done without any pulsation. Hence customer is using PCP to get a constant flow against the line pressure.

 Want to learn more about how the NETZSCH pump ranges, We can help you with your Industry application?

Get in touch with our team of experts. We can advise of best practices and recommend which pump will solve your tough challenge.

To send us an inquiry: https://shorturl.at/tvJKX

E-mail: info.nti@netzsch.com

Landline: 044 4296 5100

The designed flow rate to the CETP is 14,000 m3 / d and it has a utilization of 13,000 m3 /d with the ZLD system.

INITIAL SITUATION AND PAIN AREA

• The customer is using manpower to unload the pits. They need a minimum of 15 people, one tractor, and a minimum of 4 days to unload one pit. Due to the colloidal nature of sludge, it is difficult to get into the pit and a scaffold needs to be constructed temporarily.
• Spillage of Sludge during loading and unloading
• As per ISO Audit, manpower is not allowed for this unloading considering the corrosive nature of sludge.

Application

Process Area: Multiple Effect Evaporator & Agitated thin Film Dryer rejects

Pumped Medium

ETP Waste Water/ETP Sludge/Salt Sludge. The Density was 1350 -1500 (kg/dm3) with Particle Size <5, Solid Content 20%. Viscosity 25000 cps. Discharge Head with 60Mts of horizontal and Suction Head with 6Mts Negative.

Nature of Salt Sludge

Salt sludge is an escape media from the mother liquor during the MEE process.

Salt sludge is sticky and colloidal in nature and it releases water during the suction process of pumping.

Application

Service Area: Homogenization & Secondary Clarifier Bio Sludge

Pumped Medium

ETP Waste Water/ETP Sludge/Bio Sludge. The Density was 1350 -1700 (kg/dm3) with Particle Size <5, Solid Content 22%. Viscosity 25000 cps. Discharge Head with 60Mts of horizontal and 4Mts Vertical.

Nature of Bio Sludge

Bio sludge is from the homogenization tank and secondary clarifier and the sludge is fed into the centrifuge for solid separation.

NETZSCH SOLUTION

As a Solution, we proposed our Rotary Lobe Pump for handling this sludge and to increase client confidence proposed an RLP trial at the site.

• Due to the nature of sludge, the suction pipes get choked when we are running at 50Hz, hence we ran the pump between 25Hz to 50Hz.
• The pump consumes 22 Amps as a maximum current for transferring the salt sludge from the pit to the solar pam for a distance of 60. And for transferring the bio sludge it consumes only 15Amps.
• Our T1 XLB-2 Pump takes only 16 hours to empty one pit whereas it took 4 days without a pump.
• They used only 3 men during this process to take care of the suction side of the hose from choking and not to run the pump empty where they needed 15 people without a pump.
• Cost-saving: Total cost saving per year Approx. 9 - 10 Lacs.
• No spillage of sludge using a pump.
• No risk of using manpower to handle this corrosive media.
• Able to fulfill the requirement of ISO Audit.
• Ease of cleaning the pump and pipeline with water.
• Movement of the pump is easy with a trolley-mounted pump system and hence shall be used for various services at different locations of the plant.

• Pump Model: T1 XLB-2
• Flow Rate: 15m3/hr @261 rpm
• Pump Housing: Gg25
• Rotor: Trilobe-S65L (NBR)
• Rated Power: 30 kW

• The flow rate in proportion to the rotational speed
• High dosing precision
• Constant, low-pulsation conveyance
• smooth conveyance of shear-sensitive media
• Low life cycle costs and easy servicing (FSIP®)
• Pump design and accessories in accordance with national and international standards, as well as customized models
